The Coronado 65
The Coronado 65
The Coronado 65 offers a big American speaker sound that is great alternative to vintage Oxfords, Utahs and the like. Using a smooth cone and british-style edge treatment, it offers a deeper low-end than our Springfield, with a softer top end response, and light compression and breakup when you lean-in. Its silky top-end is a great fit for bright guitars and amps that need more twang and less sting.
Made in USA.
Regular price
$155.00
Regular price
Sale price
$155.00
Unit price
/
per
Couldn't load pickup availability
Speaker Data
OVERVIEW
- 65W power rating
- Treated smooth cone
- Powder-coated steel frame
- Genuine cork gasket
- Unpackaged Speaker Weight: 8.5 lbs
- Handmade in the USA exclusively for DIXON by WGS
MOUNTING INFORMATION
- Rim Outer Diameter: 12.1875”
- Overall depth: 5.0625”
- Cut-out diameter: 10.875”
- Mounting slot dimensions: 0.25” x 0.35"
- Bolt Holes Diameter (8 total): 0.25”
- Mounting Hole PCD: 11.75”
THIELE-SMALL PARAMETERS
- Resonant Frequency (Fs): 95.7 Hz
- DC Resistance (Re): 7.5Ω
- Coil Inductance (Le): 0.28 mH
- Mechanical Q (Qms): 14.56
- Electromagnetic Q (Qes): 0.73
- Total Q (Qts): 0.69
- Compliance Equiv. Vol. (Vas): 19.7 cu ft
- Mech. Compliance of Susp. (Cms): 0.1 mm/N
- BL Product (BL): 12.83 T-M
- Diaphragm Mass + Airload (Mms): 26.7 grams
- Surface Area of Cone (Sd): 366.1
- Sound Pressure Level (spl): 99.4 db
